Use JavaScript to send data to LMS with SCORM 2004 4th edition

Hi all,

There are many discussions on this topic but I haven't seen a full script using SCORM 2004 so I thought I could share what I've used to report data that includes detailed question text and user responses back to LMS with SCORM 2004.

For this code, I used in Workday Learning LMS but I think it should work on other LMSs. The code below is just showing the basic to report data back to LMS. So you will most likely use variables to feed cmi.interactions.

// For SCORM2004 only
var player = GetPlayer(); //talk to Storyline

function findLMSAPI(win) {
 if (win.hasOwnProperty("GetStudentID")) return win;
 else if (win.parent == win) return null;
 else return findLMSAPI(win.parent);
}
var lmsAPI = findLMSAPI(this);


//These lines will be used to set score value in SCORM2004
var finalRawScore = player.GetVar("zScore");
var passPercent = player.GetVar("zPassingPercentage");
var scoreScale = finalRawScore/100;

//Set score value here. These 4 lines are necessary for SCORM2004
 SCORM2004_objAPI.SetValue('cmi.score.scaled', scoreScale);
 SCORM2004_objAPI.SetValue('cmi.score.raw', finalRawScore);
 SCORM2004_objAPI.SetValue('cmi.score.min', '0');
 SCORM2004_objAPI.SetValue('cmi.score.max', '100');


//Here is the code to report question text and user responses back to LMS.
//These fields were tested in Workday Learning LMS and were necessary for reporting.
//You can also use variables to feed cmi.interactions. The 0 here means the first record.

 SCORM2004_objAPI.SetValue('cmi.interactions.0.id', '001');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.description', 'question 1 text here');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.objectives.0.id', '001');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.type', 'fill-in'); //refer to note1 below
 SCORM2004_objAPI.SetValue('cmi.interactions.0.timestamp', '2020-12-23T10:00:00');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.learner_response', 'This_is_a_TEST_response');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.result', 'neutral'); //refer to note2 below

//note1 (“true-false”, “choice”, “fill-in”, “long-fill-in”, “matching”, “performance”, “sequencing”, “likert”, “numeric” or “other”, RW) Which type of interaction is recorded
//note2 “correct”, “incorrect”, “unanticipated”, “neutral”


//determine if the user passed or failed. And if you would like the course to mark as completed or not if the user failed.
if (SCORM2004_objAPI.GetValue('cmi.score.raw') >= passPercent)
 {
 SCORM2004_objAPI.SetValue("cmi.success_status","passed");
 SCORM2004_objAPI.SetValue("cmi.completion_status","completed");

 }
 else
 {

 SCORM2004_objAPI.SetValue("cmi.success_status","failed");
 SCORM2004_objAPI.SetValue("cmi.completion_status","incomplete");
//can change to completed if you want the course to be marked as completed even if the user failed.

 }



Here is an example of using the Storyline variables to feed cmi.interactions.

var Q1_ID = player.GetVar("Q1_ID");
var Q1_Description = player.GetVar("Q1_QuestionDescription");
var Q1_Response = player.GetVar("Q1_Response");
var Q1_Result = player.GetVar("Q1_Result");
var Q1_Timestamp = player.GetVar("Q1_Timestamp");


 SCORM2004_objAPI.SetValue('cmi.interactions.0.id', Q1_ID);
 SCORM2004_objAPI.SetValue('cmi.interactions.0.description', Q1_Description);
 SCORM2004_objAPI.SetValue('cmi.interactions.0.objectives.0.id', Q1_ID);
 SCORM2004_objAPI.SetValue('cmi.interactions.0.type', 'fill-in');
 SCORM2004_objAPI.SetValue('cmi.interactions.0.timestamp', Q1_Timestamp);
 SCORM2004_objAPI.SetValue('cmi.interactions.0.learner_response', Q1_Response);
 SCORM2004_objAPI.SetValue('cmi.interactions.0.result', Q1_Result);

Note that the timestamp format would need to be like this: '2020-12-23T10:00:00'. So when you set up the Storyline variables to store timestamp, you would need to use JavaScript to convert current time. Here is the code to convert the time to this format.

//convert local time to ISO format and remove millisecond with slice
var date = new Date();
var JStimestamp = new Date(date.getTime() - (date.getTimezoneOffset() * 60000)).toISOString().slice(0,-5);

player.SetVar("Q1_Timestamp", JStimestamp);  //send value back to the Storyline variable.



For the complete list of SCORM 2004 runtime reference, visit:

https://scorm.com/scorm-explained/technical-scorm/run-time/run-time-reference/
