JavaScript - Change state, if cursor position is within xMin/xMax of Object.

Hi,

I am trying to create a visual indicator for a table so that learners see in which collumn and row the cursor currently is.

I created an object for each collumn and row.
Now I am trying to change the state with JS, but it does not work.

What am I doing wrong here

const o1 = object('6nKnekJjyCF');
const o2 = object('6rTfKlrkffu');
const o3 = object('5YGRHUhpman');
const o4 = object('5oWNAuBFQS9');
const o5 = object('5es1edRLL5N');
const o6 = object('5Y0WLnqNi85');
const o7 = object('6XA7DdXsjXT');
const o8 = object('6G4nVLkSpzg');
const o9 = object('6MWHGvfKj1i');
const o10 = object('6eHgJLZFv0z');
const o11 = object('6NhKQJivvJo');
const o12 = object('6PJRLuwZZUT');
const o13 = object('6Riz75gsucC');
const o14 = object('6dNn7Zlc3Fe');
const o15 = object('67Lt13EAIeL');
const o16 = object('6hx6477vrWe');
const o17 = object('6MuvcaUW0kA');
const o18 = object('6JdTBlPMvEe');
const o19 = object('6mjaSU5mlJ2');
const o20 = object('6n9mjXnS3g8');
const o21 = object('5h7z2HMOD6H');
const o22 = object('6XHcmao1COC');
const s1 = object('6p0AmxXw14N');
const s2 = object('5zjVvVlYQ01');
const s3 = object('5qQxtId7Amz');
const s4 = object('6M17i9NeMrw');
const s5 = object('5WQ15Gpnyr0');
const s6 = object('6EcoeJeiIXR');
const s7 = object('5fAeoQpuuqH');
const s8 = object('6Xg7eVdOm39');
const s9 = object('6rB4fWk4rhs');
const s10 = object('5u84t7qJZPv');
const s11 = object('5XbluraXP9S');
const s12 = object('5vW4SJ9sAF9');
const s13 = object('5xmEI2CxN1T');
const s14 = object('65LKZEujAEJ');
const s15 = object('6G0ytVPJBH7');
const s16 = object('62sCo2NeQXG');
const s17 = object('5tKsUgZBybr');
const s18 = object('5dxwyNcYfnw');
const s19 = object('5alzmMapgWq');
const s20 = object('64ZsDMiiFeV');


function createObjectData(id) {
  const el = document.getElementById(id);
  const rect = el.getBoundingClientRect();
  return {
    el,
    id,
    xMin: rect.left,
    xMax: rect.right,
    yMin: rect.top,
    yMax: rect.bottom,
    state: "Normal"
  };
}

const objekteX = oIDs.map(createObjectData);
const objekteY = sIDs.map(createObjectData);


document.addEventListener("mousemove", (event) => {
  const x = event.clientX;
  const y = event.clientY;

  objekteX.forEach(obj => {
    const inside = x >= obj.xMin && x <= obj.xMax;
    if (inside && obj.state !== "Ein") {
      obj.state = "Ein";
      obj.el.style.outline = "2px solid green";
    } else if (!inside && obj.state !== "Normal") {
      obj.state = "Normal";
      obj.el.style.outline = "none";
    }
  });

  objekteY.forEach(obj => {
    const inside = y >= obj.yMin && y <= obj.yMax;
    if (inside && obj.state !== "Ein") {
      obj.state = "Ein";
      obj.el.style.outline = "2px solid blue";
    } else if (!inside && obj.state !== "Normal") {
      obj.state = "Normal";
      obj.el.style.outline = "none";
    }
  });
});

3 Replies

  • Nedim's avatar
    Nedim
    Community Member

    Your script has a few issues that will cause it to break. For example:

    const objekteX = oIDs.map(createObjectData);
    const objekteY = sIDs.map(createObjectData);

    In this code, oIDs and sIDs are not defined anywhere, so this will result in a ReferenceError. JavaScript needs those variables to be declared and assigned before you can call .map() on them. Is this what you're trying to achieve with this interaction?

  • Perhaps you were looking for this effect:

    https://360.articulate.com/review/content/219630e2-65b9-46be-8015-4a7cf31fd0aa/review

    If so, see the modified code in your attached project file.

    As Nedim mentioned, you have some errors in your original code. Also, you may want to include the outlines into the states for simplicity. I did not directly reference the DOM elements in the example, and the object().style parameter will not adjust the outlines of the slide objects because of how they are formed.

    • StefanKoler-a6f's avatar
      StefanKoler-a6f
      Community Member

      Thank you Nathan, that is excactly what I was trying to acchieve :-)
