gsap transformOrigin not working in Storyline
Hi,
I'm trying to make an interactive graph where the user hovers over the bar on the graph and the height of the bar grows upwards with animation. I've been trying to use gsap with scaleY and tran...
Nedim
6 months agoCommunity Member
transformOrigin won’t work with GSAP if the target element is referenced using the object() function alone. To achieve the desired effect, you have two options:
- Use GSAP to animate the actual DOM element (e.g., via document.querySelector(...) targeting the data-model-id).
- Use the Web Animations API, which can work directly with the object returned by object() if it supports animation.
Option 1:
const box = document.querySelector('[data-model-id="6FmKrDaANZj"]');
gsap.to(box, {
transformOrigin: "bottom left",
duration: 2,
scaleY: 2,
});
Option 2:
const box = object('6FmKrDaANZj');
box.style.transformOrigin = 'bottom left';
box.animate(
[
{ transform: 'scaleY(1)' },
{ transform: 'scaleY(2)' }
],
{
duration: 2000,
easing: 'cubic-bezier(0.42, 0, 0.58, 1)',
fill: 'forwards'
}
);
DaveSundberg
6 months agoCommunity Member
querySelector worked! Thank you for the suggestion!
- Nedim6 months agoCommunity Member
Great!
